[Vehicle technical parameters] | |||
Product trademark | Chengli brand | product model | CL5182GXW6ACC |
product name | suction -type sewer scavenger | Tank volume (m3) | 13 |
gross mass （Kg） | 18000 | outline dimension （mm） | 8100×2500×3450 |
curb weight （Kg） | 9400 | Front suspension/rear suspension (mm) | 1430/1970 |
Number of approved occupants (persons) | 3 | Top speed (Km/h) | 89 |
axle weight （Kg） | 6500/11500 | ||
[Chassis Technical Parameters] | |||
Chassis model | ZZ1187K501GF1 | Name of chassis | truck chassis |
brand name | The Haworth brand | manufacturing enterprise | Sinotruk Jinan Truck Co., LTD |
number of axles | 2 | Number of tires | 6 |
wheel base （mm） | 4700 | ||
tyre size | 10.00R20 18PR | ||
Number of steel spring plates | front gauge （mm） | 1950 | |
Type of fuel | diesel oil | rear track （mm） | 1848 |
Emissions are based on standards | GB17691-2018 National VI | ||
engine type | Engine manufacturing enterprise | displacement （ml） | power （Kw） |
MC07.25-60 | China Heavy Duty Automobile Group Co., LTD | 6870 | 188 |
Vacuum suction trucks are specialized vehicles designed to collect, transport, and safely dispose of liquid and semi-liquid waste. The HOWO 12 Cubic Meter Vacuum Suction Truck offers a large-capacity solution, combining robust engineering with high operational efficiency.
Its 12m³ tank makes it ideal for municipal sanitation, industrial waste collection, and emergency spill response. Built on the reliable HOWO chassis, it ensures stability, durability, and cost-effectiveness. Operators benefit from reduced cycle times, safe suction operations, and reliable performance even under demanding conditions.
With urbanization, industrial development, and stricter environmental regulations, vacuum suction trucks with 12m³ capacity have become essential for efficient waste management. This guide provides a complete overview of the vehicle, covering technical specifications, operational benefits, applications, maintenance, and SEO-optimized content for digital publication.
A vacuum suction truck, also known as a vacuum tanker or sewage suction vehicle, is a specialized truck equipped with a vacuum pump and a storage tank to efficiently collect and transport liquid and semi-liquid waste. These trucks are essential in municipal sanitation, industrial facilities, construction sites, and emergency environmental response.
Collection and transport of sewage, sludge, and industrial liquids
Emergency spill response and cleanup
Hydro-excavation and site cleaning operations
Maintenance of municipal drainage and sewer networks
| Term | Definition |
|---|---|
| Vacuum Tanker | Vehicle with a tank and suction system to collect liquid or semi-solid waste |
| Sludge | Semi-solid waste typically from septic tanks, industrial processes, or municipal sewage |
| Hydro Vacuuming | Process combining high-pressure water with suction to remove waste efficiently |
| Chassis | Vehicle frame supporting the engine, tank, and operational components |
| Suction Pump | Device generating vacuum pressure to draw liquid or semi-solid waste into the tank |
High Capacity: 12m³ tank allows larger volumes of waste per cycle, improving efficiency
Durable Chassis: HOWO chassis ensures stability, durability, and long-term reliability
Efficient Suction: Advanced pump and hose systems minimize downtime
Versatile Applications: Suitable for municipal, industrial, and construction operations
Reduced Labor: Mechanized suction reduces manual handling and operational effort
Municipal sewage and drainage maintenance
Industrial wastewater transport
Construction site cleaning and slurry removal
Emergency spill and flood response
Large-scale environmental sanitation projects
HOWO vacuum suction trucks are globally recognized for their robust chassis, reliable engines, and efficient operational performance. The 12m³ configuration balances high volume capacity with maneuverability, making it suitable for urban and industrial operations.
High durability and load-bearing capacity
Powerful diesel engines capable of continuous operation
Flexible chassis options for mounting different tank types and vacuum systems
Long service life with minimal maintenance requirements
Globally available spare parts and service support
| Component | Function |
|---|---|
| Chassis | Supports engine, tank, and operational systems |
| Vacuum Tank | Stores collected liquid and semi-liquid waste safely |
| Vacuum Pump | Creates suction to draw waste into the tank |
| Hoses & Valves | Direct liquid from the source to the tank |
| Control System | Monitors and controls suction pressure and pump operation |
| Safety Features | Includes pressure relief valves, anti-corrosion coating, and emergency shutdown mechanisms |
The vacuum pump reduces air pressure in the tank, creating a vacuum that draws waste from pipelines, septic tanks, or industrial containers into the tank. Proper hose diameter, tank design, and pump capacity are essential to maintain suction efficiency and avoid blockages.
Cleaning urban sewage pits, storm drains, and drainage systems
Emergency floodwater removal and sanitation
Maintenance of underground sewer pipelines
Transporting industrial wastewater to treatment facilities
Cleaning tanks, pipelines, and processing equipment
Hydro-excavation and construction site cleanup
Spill response for contaminated liquids
Septic tank cleaning and maintenance
Emergency wastewater removal in urban and industrial areas
High suction and discharge rates reduce operational cycle times
Compact maneuverable design for urban and industrial environments
Multi-functional for liquid and semi-solid waste
Robust construction ensures long-term operational reliability
Reduced fuel consumption compared to larger trucks
Lower labor costs due to mechanized suction operations
Durable design provides long-term cost efficiency
Minimal downtime with preventive maintenance
| Parameter | Specification |
|---|---|
| Vehicle Model | HOWO 12m³ Vacuum Suction Truck |
| Tank Volume (m³) | 12 |
| Gross Vehicle Weight (Kg) | 25,000 |
| Rated Payload (Kg) | 11,500–12,000 |
| Curb Weight (Kg) | 13,000–14,000 |
| Overall Dimensions (mm) | ~9,300 × 2,550 × 3,650 |
| Number of Axles | 3 |
| Wheelbase (mm) | 4,350+1,350; 4,750+1,350; 5,400+1,350 |
| Tires | 10, 11.00-20 16PR |
| Fuel Type | Diesel |
| Emission Standard | National VI / Euro VI |
| Engine Model | Manufacturer | Displacement (ml) | Power (kW) |
|---|---|---|---|
| WD615.69 | SINOTRUK HOWO | 9,726 | 260 |
| YC6J210-50 | Yuchai Engine | 6,300 | 210 |
| B6.2NS6B260 | Dongfeng Cummins | 6,200 | 191 |
Performance depends on suction rate, pump efficiency, hose length, and engine reliability. Monitoring fuel consumption, cycle times, and waste-handling capacity ensures optimal performance. Proper preventive maintenance of hoses, valves, and the tank extends service life and ensures safety.
Selection depends on tank volume, waste type, operational environment, and budget. Proper assessment ensures operational efficiency, safety, and cost-effectiveness.
| Factor | Consideration |
|---|---|
| Tank Volume | Matches average waste volume per cycle |
| Suction Power | Must handle sludge, sewage, or industrial liquids efficiently |
| Chassis Strength | Supports payload and ensures stability |
| Engine Performance | Continuous operation without overheating |
| Maintenance Cost | Availability of spare parts and service support |
Vacuum suction trucks must comply with environmental and safety standards:
Pressure relief valves prevent over-pressurization
Anti-spill tank design reduces environmental contamination
Operator protective equipment ensures safety
Compliance with emissions and noise regulations
Engine oil, coolant, and fuel levels
Lubricate vacuum pump and moving parts
Inspect hoses, valves, and seals
Check brakes, tires, and operational controls
Lubricate moving components
Clean filters and gauges
Inspect hydraulic system and tank integrity
Test vacuum system performance
Anti-freeze measures for cold climates
Insulation for hoses and tank
Cold-weather operational protocols
HOWO 12m³ vacuum suction trucks are increasingly popular due to urbanization, industrial growth, and environmental regulations. Technological improvements in vacuum pumps, chassis durability, and fuel efficiency continue to drive global demand. Their rear-mounted configuration and large capacity make them suitable for municipal, industrial, and emergency operations.
Clogging and Pump Blockage – Regular cleaning and proper hose sizing prevent downtime
Tank Corrosion – Use anti-corrosion coatings or stainless steel tanks
Operator Safety – Training and emergency shutdown systems reduce risks
Maintenance Delays – Preventive maintenance ensures reliable performance
What is the advantage of a 12m³ vacuum suction truck?
High capacity reduces the number of cycles required for waste transport, improving efficiency.
Which sectors benefit most?
Municipal sanitation, industrial wastewater management, construction, and emergency spill response.
Can it handle sludge and semi-solid waste?
Yes, designed for both liquid and semi-solid waste; large solids may require pre-processing.
Why choose HOWO chassis?
Reliable engines, robust chassis, global service network, and low maintenance cost.
The HOWO 12 Cubic Meter Vacuum Suction Truck is a high-capacity, durable, and efficient solution for municipal, industrial, and emergency operations. Its robust chassis, reliable vacuum system, and rear-mounted design ensure stable performance, operational efficiency, and environmental compliance, making it ideal for large-scale waste management projects.
