Product Model: CL5041TXSBEV
Brand: Chengli
Vehicle Specifications:
Gross Vehicle Weight (Kg): 4495
Superstructure Volume (m³): 3.8 (1.8 m³ clean water tank + 2 m³ dust container)
Electric Motor Rated Power (Superstructure): 15 kW
Overall Dimensions (mm): 5570 × 1650 × 2180
Curb Weight (Kg): 3580
Recommended Charging Time (at suggested power): ~0.5–1 hour
Number of Axles: 2
Wheelbase (mm): 3000
Chassis Model: EQ1040TACEV4
Chassis Motor Maximum Power: 70 kW
Number of Tires: 6
Tire Specifications: 185R15LT 8PR
Fuel Type: Pure electric
Recommended Charging Station Power: 120 kW
Battery Brand: CATL
Battery Type: Lithium Iron Phosphate (LiFePO₄)
Battery Capacity: 66 kWh
Battery Pack Rated Voltage: 386.4 V
Key Features:
The clean water tank fully utilizes onboard space with a large capacity of 1.8 m³. The waste/dust container uses a single-layer carbon steel structure with a tipping unloading design.
Each vehicle is tested by dedicated personnel in simulated complex operating environments to ensure reliability before delivery.
The pure electric motor ensures low operational noise during all cleaning tasks.
Safety and Operating Notes:
Keep unauthorized personnel away from the vehicle while it is operating.
During operation, avoid running over large objects such as bricks or heavy debris.
When emptying the wastewater tank, first open the rear door drain valve. Only open the rear door to dump waste after the drain valve has fully discharged.
Waste discharge must be performed in designated disposal areas. No personnel should stand within 5 meters of the rear door of the waste tank while dumping. Do not enter the vehicle or operate it normally until the waste container has fully lowered and locked into place.
The Dongfeng Tuyi CL5041TXSBEV sweeper truck marks a significant advancement in modern street cleaning equipment. As governments and cities worldwide pursue cleaner air, reduced emissions, and sustainable urban infrastructure, electric sweeping vehicles are now essential components of public sanitation fleets. This guide provides a detailed, SEO‑optimized explanation of the Dongfeng Tuyi CL5041TXSBEV — its design, capabilities, technology, advantages, specifications, applications, safety considerations, and operational best practices.
Pure electric sweeping trucks like the CL5041TXSBEV combine environmental friendliness with operational efficiency, addressing the dual goals of urban cleanliness and sustainability. By eliminating diesel consumption and lowering noise pollution, electric sweepers help city authorities improve public health outcomes and reach climate targets.
This comprehensive article is designed for sanitation professionals, fleet managers, public works planners, content creators, and anyone seeking deeply informative, well‑structured content about electric street sweepers optimized for web visibility.
A sweeper truck is a specialized roadway and pavement cleaning vehicle engineered to remove debris, dust, dirt, and waste from streets, parking lots, industrial areas, and other paved surfaces. Traditionally powered by diesel engines, modern sweepers increasingly use electric or hybrid power systems to enhance sustainability.
The essential function of a sweeper truck is to improve surface cleanliness, reduce airborne dust, and support public health and environmental quality. Sweepers are distinguished by integrated systems including brush mechanisms, vacuum suction, storage tanks, and optional water spraying to suppress dust.
In recent years, electric sweeper trucks have grown rapidly in popularity due to stricter emission regulations, rising fuel costs, and greater emphasis on sustainability. Electric sweepers use rechargeable battery systems and high‑efficiency electric motors to operate without combustion emissions, offering lower operating costs and quieter performance.
Electric models are especially valuable in noise‑sensitive areas, such as residential neighborhoods, business districts, and hospitals, where quiet and emission‑free operation is a priority. By eliminating diesel exhaust, pure electric sweeping trucks improve urban air quality and support sustainability goals.
The Dongfeng Tuyi CL5041TXSBEV combines electric propulsion with proven sweeping technology. It is designed for efficient cleaning of city streets, industrial compounds, parking areas, campuses, and public facilities.
Key performance priorities of the CL5041TXSBEV include:
Zero Emission Operation: All‑electric power eliminates diesel exhaust.
Efficient Sweeping and Vacuum Suction: Side brushes and central sweeping heads remove debris efficiently.
Dust Suppression System: Integrated spraying reduces airborne dust during cleaning.
Compact and Maneuverable Design: Ideal for tight urban spaces.
High‑Capacity Water and Waste Tank: Designed for extended work cycles.
This truck belongs to a new generation of electric sanitation vehicles that deliver environmentally conscious performance, operational efficiency, and low lifecycle cost.
Electric sweeper trucks combine several subsystems:
Electric Propulsion
Modern electric sweepers use battery systems to power both the wheels and auxiliary equipment. Large onboard batteries supply energy to the traction motor and cleaning systems. Electric drives provide smooth acceleration and regenerative braking, increasing overall efficiency.
Brush and Vacuum System
Rotating brushes (side and central) loosen dirt and guide debris toward a suction nozzle. A vacuum system then draws debris into a storage hopper using airflow generated by a blower or fan.
Water Spray System
High‑pressure water tanks and spray nozzles wet the surface ahead of the vacuum system to suppress dust and improve cleaning performance. Adjustable water jets allow for controlled dust management without oversaturation.
Debris Storage and Disposal
Swept material is stored in a dedicated hopper. When the hopper reaches capacity, a tipping or unloading mechanism allows for safe disposal at approved waste facilities.
Intelligent Controls
Smart control systems enable operators to adjust broom speed, suction power, and spray volume. Many modern vehicles include CAN bus or PLC controllers for optimized operation and diagnostic support.
This integrated process ensures thorough cleaning, minimized dust emission, and greater operational safety.
| Component | Description |
|---|---|
| Vehicle Model | CL5041TXSBEV Electric Sweeper Truck |
| Drive System | Pure electric propulsion |
| Electric Motor Power | 70 kW (chassis motor) |
| Upper Motor Power | 15 kW (sweeper‑specific equipment) |
| Battery Type | LiFePO₄ lithium iron phosphate |
| Battery Capacity | 66 kWh |
| Rated Battery Voltage | 386.4 V |
| Charging Time | ~0.5–1 hour (120 kW charger recommended) |
| Gross Vehicle Weight | 4495 kg |
| Curb Weight | 3580 kg |
| Overall Dimensions | 5570 × 1650 × 2180 mm |
| Wheelbase | 3000 mm |
| Tire Configuration | 6 tires, 185R15LT 8PR |
| Water Tank Volume | 1.8 m³ |
| Debris Hopper Volume | 2.0 m³ |
| Total Superstructure Volume | 3.8 m³ |
The following table expands on key dimensions and capabilities:
| Specification | Value |
|---|---|
| Sweeping Width | Adjustable, dependent on brush configuration |
| Operational Speed | 0–20 km/h (typical cleaning range) |
| Maximum Broom Diameter | 800–900 mm (model dependent) |
| Water Pump Pressure | 8–12 MPa (spray system) |
| Water Pump Flow | 100–150 L/min (typical) |
| Vacuum Blower Capacity | High airflow for dust capture |
| Brush Drive | Hydraulic or electric |
| Controller | CAN/PLC integrated management |
| Charging Standard | 120 kW DC fast charging recommended |
Electric sweepers operate efficiently in both dry and wet conditions, providing dust suppression and debris capture without harmful emissions.
With no combustion engine, electric sweepers produce no tailpipe emissions, helping reduce urban pollution and meet environmental targets.
Electric motors operate at low sound levels, making these vehicles ideal for use in parks, residential districts, and early morning or late‑night street cleaning.
Integrated water spray systems and vacuum suction work together to capture airborne particles, improving air quality in the cleaning zone.
Reduced fuel consumption and fewer mechanical parts lower overall maintenance expenditures and extend service life.
Compact chassis and electric torque characteristics allow easy navigation through narrow streets and congested zones.
Advanced electrical control units provide precise adjustments for sweep speed, suction intensity, and spray pressure, optimizing cleaning performance.
Electric street sweepers like the CL5041TXSBEV are widely used in:
Urban road maintenance and street cleaning
School campuses and pedestrian zones
Stadiums and event grounds
Industrial yard cleaning
Parking lot and facility maintenance
Residential community sanitation
Dust control at construction sites
Their zero‑emission nature makes them especially suitable for densely populated areas and regions with strict air quality regulations.
To operate the CL5041TXSBEV effectively:
Pre‑Operation Checks: Verify battery charge, inspect brushes, confirm water levels, and ensure no obstructions.
Activate Systems: Use the control panel to power up sweeping, suction, and water spraying.
Adjust Parameters: Set brush speed and vacuum intensity based on debris type and surface conditions.
Monitor Performance: Observe water levels, battery status, and debris tank capacity during operation.
Efficient Navigation: Maintain steady, moderate driving speeds during cleaning to maximize effectiveness.
Safe Shutdown: After use, power down systems and perform routine cleanup of components.
Following standard operating procedures ensures consistent cleaning and prolonged equipment life.
Safety remains a priority when using heavy sanitation equipment:
Operators should maintain clear sightlines, use mirrors and cameras, and avoid excessive speeds.
Avoid sweeping over large objects such as bricks or sharp debris that may damage equipment.
Only discharge waste at designated sites. Maintain safe distances when unloading debris, keeping individuals at least 5 meters away from the vehicle’s rear.
Ensure emergency stop switches and alarms are functional before starting work.
Avoid allowing unrelated personnel near the vehicle while in operation.
Following these safety guidelines reduces risk and promotes secure work environments.
Battery Maintenance
Charge according to manufacturer recommendations.
Avoid full depletion of battery charge cycles.
Inspect battery pack for wear and damage.
Brush & Suction System
Clean debris brushes after each use.
Replace worn bristles promptly.
Inspect vacuum hoses and suction nozzles for blockages.
Water System
Flush water tanks regularly.
Monitor water pump performance.
Electrical System
Inspect wiring harnesses and connectors.
Update control software when available.
Regular maintenance increases uptime and extends equipment longevity.
Q: How long does it take to charge the sweeper truck?
A: With a recommended 120 kW charging station, the CL5041TXSBEV can recharge in 0.5–1 hour, optimizing operational readiness.
Q: Is the sweeping depth adjustable?
A: Yes — brush rotation speed and vacuum suction can be adjusted depending on surface conditions and debris type.
Q: Can the sweeper handle both dry and wet debris?
A: Yes — with integrated vacuum suction and water spray, it can handle mixed debris effectively.
Q: Is this truck suitable for narrow streets?
A: Absolutely. Its compact profile and electric drive allow precise maneuvering in urban environments.
Q: Does the electric sweeper require special licensing?
A: Licensing depends on local regulations; consult local authorities for specific requirements.
The Dongfeng Tuyi CL5041TXSBEV Sweeper Truck is a leading example of sustainable sanitation equipment for modern urban and industrial applications. Its electric design, advanced sweeping technology, and intelligent control systems deliver powerful cleaning performance while minimizing environmental impact. Ideal for cities, campuses, industrial areas, and more, electric sweepers are setting a new standard in street cleaning.
As air quality standards tighten and cities transition to green infrastructure, electric sweeping trucks like the CL5041TXSBEV play a critical role in supporting clean, healthy, and efficient urban environments.
