New Energy Washing and Sweeping Vehicle
| Product Name | Pure Electric Washing and Sweeping Vehicle | Model | CL5180TXSABEV |
Gross Weight (Kg) | 18000KG | Motor Brand | Times Electric |
Wheelbase (mm) | 5000 | Dimensions (mm) | 8850 x 2550 x 3390 |
Curb Weight (Kg) | 13070KG | Tire Specification | 295/80R22.5 |
Chassis Configuration: Uses the CL1180JABEV type Class II cargo vehicle chassis from Chengli Automobile Group Co., Ltd. The vehicle is equipped with advanced components including motor, battery, and electronic control from leading industry brands. The design supports energy recovery, integrated multi-stage reduction, ultra-low speed stable control (0.5 km/h), dual-source steering, and intelligent safety gear shifting, achieving high stability, reliability, low noise, and comfortable driving.
Chassis Motor: Equipped with TZ220XYC01 permanent magnet synchronous motor from Hangzhou Times Electric Technology Co., Ltd. The motor features a condensation-proof motor junction box, effectively preventing condensation inside the box. It allows safe operation during hot/cold cycles, avoiding high-voltage system failures caused by condensation. The motor is simple to assemble, reliable, and operable in humid and rainy conditions.
Chassis Battery: Uses original battery packs produced by CATL (Contemporary Amperex Technology Co., Ltd.), consisting of battery cells, modules, and battery management system. The battery has a high protection rating (IP68), leading in domestic standards, offering waterproof, dustproof, shockproof, and explosion-proof performance. It ensures high safety, long life, and stable reliability.
Body Configuration: Manufactured according to official appearance standards. The vehicle is modified from a pure electric Class II chassis, including the fan, clean water tank, garbage bin, left and right sweep brushes, lowering system for dust suppression, left and right high-pressure nozzles, suction high-pressure water spray, pneumatic system, hydraulic system, dedicated hydraulic lifting system, and sub-frame.
Left and Right Sweep Brushes: Single-brush setup reduces usage and maintenance costs. Spraying devices on the brushes suppress dust.
Side Sweep Control: Enables separate operation of left and right sweeps.
Suction Cup Width: 2300 mm, ensuring an operational width greater than 3.5 m.
Adjustable Nozzles: Four height-adjustable suction nozzles for optimal suction and cleaning efficiency.
High-Pressure Spray: Nozzles located inside the suction cups maximize cleaning effect. Brackets for left/right high-pressure spray are simple, sturdy, and ensure optimal washing performance.
Rear LED Lights: Headlights and warning lights ensure operational safety.
Sweeping Disk: Durable, reliable, low-failure design. Uses normal-temperature hydraulic solenoid valves and Schneider electrical components for key controls.
CAN Bus System: For integrated operation.
Water Tank Capacity: 8 m³; Garbage Bin Capacity: 8 m³. Efficient use of onboard space allows a total capacity of 8 m³.
Garbage Bin: 304 stainless steel, tipping design with high-pressure self-cleaning. Self-cleaning assists material discharge and cleans the internal bin.
Additional components include chassis certificate, vehicle certificate, and registration invoice.
Urban environments today demand higher standards of cleanliness, sustainability, and efficient municipal services. One of the most effective solutions for modern city cleaning is the Chengli pure electric sweeper truck. These vehicles combine zero-emission technology with powerful performance, low operational cost, and improved public health outcomes.
This comprehensive guide explores Chengli Pure Electric Sweeper Trucks, including their definition, working principles, key benefits, common applications, detailed specifications, maintenance requirements, environmental impact, buyer considerations, and future trends.
A Chengli pure electric sweeper truck is a specialized sanitation vehicle designed for outdoor surface cleaning, fully powered by electricity. Unlike diesel or gasoline sweepers, these trucks produce zero emissions and operate quietly.
Key features include:
Zero local emissions
Low noise operation
Efficient debris collection
Modular, durable components
Adaptability for various urban environments
Sweeper trucks are widely used on roads, parking lots, industrial estates, pedestrian areas, campuses, and residential communities.
| Component | Purpose |
|---|---|
| Electric Motor | Drives the vehicle and sweeper system |
| Battery Pack | Powers all electrical functions |
| Brush System | Rotary brushes clean debris from the surface |
| Vacuum Suction | Removes dust and fine particles |
| Water Spray System | Suppresses dust during operation |
| Hopper | Stores collected debris |
| Control Panel | Monitors and controls vehicle functions |
Operator activates the sweeper truck
Side brushes sweep debris toward the main broom or suction inlet
Water sprays suppress fine dust to improve air quality
Debris and dust are collected into the internal hopper
Hopper is emptied at designated waste facilities
Electric systems allow smooth power delivery, precise brush control, and energy recovery for extended operational range.
| Type | Tailpipe Emissions |
|---|---|
| Diesel/Gasoline Sweepers | High CO₂ and particulate emissions |
| Chengli Pure Electric Sweepers | Zero tailpipe emissions |
Electric sweepers help cities meet environmental standards and improve air quality.
Electric motors produce much less noise than combustion engines, reducing urban noise pollution.
While the initial purchase price may be higher, lifetime operating costs are often lower due to reduced fuel expenses, fewer mechanical parts, and longer component life.
Electric sweepers provide consistent suction and brush force, with smart controls optimizing cleaning efficiency.
Zero greenhouse gas emissions
Reduced air and noise pollution
Supports urban sustainability goals
Reduced carbon footprint
Precise and responsive driving
Energy regeneration in some models
Easy integration with smart fleet management
Lower vibration and mechanical wear
Ideal for pedestrian zones, parks, and downtown areas
Reduced disruption in residential communities
Enhanced public experience during cleaning operations
Modern models often include:
Real-time monitoring
Automatic water control
Adjustable brush pressure
Remote diagnostics
Chengli pure electric sweeper trucks serve various sectors:
Used to maintain daily cleanliness on streets and highways, complying with noise and emission restrictions.
Large parking lots benefit from quiet, maneuverable sweepers that handle debris efficiently.
Shopping centers, business parks, and campuses maintain professional and clean environments using electric sweepers.
Universities, schools, and hospitals rely on emission-free, low-noise cleaning near sensitive areas.
Helps manage dust where particulate matter can affect operations or worker health.
Below is a generalized specification table for Chengli pure electric sweeper trucks. Actual specs vary by model.
| Category | Specification |
|---|---|
| Vehicle Type | Pure Electric Sweeper Truck |
| Drive Type | Electric Motor (AC or DC) |
| Battery Type | Lithium-ion / LFP / NMC |
| Battery Capacity | 80 – 400 kWh |
| Operating Voltage | 48V – 600V |
| Range (Full Charge) | 100 – 300+ km |
| Top Speed | 40 – 80 km/h |
| Water Tank Capacity | 500 – 3000 L |
| Hopper Volume | 3 – 8 m³ |
| Side Brush Diameter | 500 – 900 mm |
| Main Brush Width | 800 – 1800 mm |
| Control System | Digital / CANbus Integration |
| Dust Filtration | HEPA / Multi-stage Filters |
| Charging Time | 1 – 8 hours (fast/standard) |
| Ground Clearance | 200 – 350 mm |
| Turning Radius | 6.5 – 9.5 m |
| Noise Level | < 75 dB |
| Charging Mode | Description |
|---|---|
| Standard AC Charging | Balanced overnight charging |
| Fast/DC Charging | Quick charge during shifts |
| Battery Swap Stations | Modular battery replacement |
Scheduled charging to save energy costs
Grid integration for load management
Battery health monitoring
Inspect brushes for wear
Clean water nozzles
Check battery charge and wiring
Empty hopper after use
Replace filters
Rotate tires
Diagnose motor and controller
Update software firmware
Use protective equipment during maintenance
Avoid water exposure to electrical systems
Park on level ground before servicing
It uses electric propulsion instead of combustion, eliminating emissions and reducing noise.
Operating range depends on battery size and payload, typically 100–300+ km.
Yes, especially in urban and emission-controlled areas, offering similar or better performance.
Yes, with advanced filtration systems designed for heavy dust and debris.
Headings for blogs or category pages:
What Is Chengli Pure Electric Sweeper Truck
How Electric Street Sweepers Work
Environmental Advantages of Electric Sweepers
Cost Benefits Compared to Diesel Sweepers
Common Urban Sweeping Scenarios
Choosing the Right Electric Sweeper
Essential Specification Guide
Charging and Power Management Strategies
Maintenance Tips for Longevity
Future Trends in Electric Sweeper Technology
Comparison: Electric vs Hybrid vs Diesel Sweepers
FAQs About Pure Electric Sweeper Trucks
Electrification of municipal fleets is accelerating worldwide to meet sustainability goals. Smart fleet integration with GPS and predictive maintenance enhances route efficiency. Battery innovations and fast-charging solutions will continue to improve performance and operational range.
The Chengli pure electric sweeper truck represents a next-generation solution for sustainable urban cleanliness. By combining zero emissions, efficient operations, and advanced features, these vehicles are becoming essential assets for modern cities and large facilities.
This structured, keyword-rich content can be directly used for SEO-optimized blogs, category pages, or industry guides.
