| Item | Specification |
|---|---|
| Vehicle Model | CL5187TXSBEV |
| Chassis Model | EQ1180GLEVJ |
| Wheelbase | 5000 / 5300 mm |
| Body Volume | Clean Water Tank: 8 m³, Waste Tank: 7 m³ |
| Overall Dimensions (L×W×H) | 8600 × 2550, 2530, 2500 × 3350, 3300 mm |
| Rated Load | 5020, 4955 kg |
| Gross Vehicle Weight | 18,000 kg |
| Curb Weight | 12,850 kg |
| Battery Brand / Type | CATL Lithium Iron Phosphate Battery |
| Fuel Type | Pure Electric |
| Range | 300 km |
| Maximum Speed | 89 km/h |
| Battery Capacity | 267.39 kWh |
| Brake Type | Air Brake |
| Charging Time | Approx. 1 hour |
| Maximum Gradeability | ≥30% |
| Recommended Charging Pile Power | 120 kW |
| Approach / Departure Angle | 20° / 12° |
| Chassis Motor Power | 246 kW |
| Front / Rear Overhang | 1410 / 2190 mm |
| Body Motor Rated Power | 40–50 kW |
| Diaphragm Pump | Polaris |
| Body Hourly Power Consumption | 30–40 kWh |
| Electric Control System | Baimaofu |
| Body Material | Carbon steel and stainless steel water tank |
| Control Voltage | 12V |
| Operation Mode | Fully electric control |
| Tire Specification | 295/80R22.5 18PR, 295/80R22.5 16PR |
| Axle Load | 6500 kg / 11,500 kg |
| Drive System | Direct Drive + Electric PTO |
| Chassis Controller | Multi-in-one type |
| Chassis Configuration | LCD instrument, air conditioning, central locking, ABS |
| Chassis Motor Type | Permanent Magnet Synchronous Motor |
| Torque (Rated/Peak) | 1400 / 2800 N·m |
| Power (Rated/Peak) | 123 / 246 kW |
| Engine Manufacturer | Dongfeng Huashen Automobile Co., Ltd. |
| Battery Energy Density | 154.49 Wh/kg |
| Additional Configuration | Chassis battery powers the vehicle, permanent magnet synchronous motor drives; real-time speed adjustment as needed; mid-mounted four sweeping disks; Lidon motors; electromagnetic diaphragm water pump; Changyuan gear pump; Hypreese hydraulic cylinder; Alta electromagnetic valve group; maintenance-free centrifugal fan; carbon steel water and waste tanks; Schneider control switches; rear LED arrow lights; water tank low-level alarm; indoor monitoring system for reversing and operational status; maximum sweeping width 3.5 m; electrical system operated through chassis-specific working device circuit. |
| Item | Specification |
|---|---|
| Sweeping Width | 3500 mm |
| Waste Compartment Tilt Angle | ≥40° |
| Sweeping Speed | 3–20 km/h |
| Sweeping Efficiency | ≥95% |
| Maximum Sweeping Capacity | 50,000 m²/h |
| Operating Noise | < 88 dB (compliant with GB7258) |
| Number of Sweeping Disks | 2 |
| Sweeping Disk Angle | Forward Tilt: 5°–15°, Outward Tilt: 5°–10° |
Suction density: 2.0 g/cm³
Suction mass: 1.5 kg
Suction particle size: ≥50 mm
Located in the left, right, and front sweeping disks as well as suction nozzle intake
Gear pump, cycloidal motor, hydraulic cylinder, electromagnetic hydraulic valves
Composed of chassis-specific working device control circuits
Control panel includes main motor tachometer, engine oil temperature alarm, low water level alarm, and various operational switches
Motor-driven, high-temperature resistant A-belt transmission
Rated speed: 2000 rpm
Sweeping disk brackets, disks, cylinders, hoses, connecting rods, adjustment rods, hydraulic motors
Sweeping brush expanded diameter: φ600–800 mm
Sweeping disk motor speed: adjustable
Composed of nozzle body, roller, and suction pipe
Nozzle follows road surface; lifting controlled by hydraulic cylinder
Suction pipe diameter: φ150 mm
Nozzle movement controlled hydraulically and electrically; spring-loaded floating suspension
Working state: rigid edge 5–8 mm above ground
Permanent magnet synchronous motor
Motor quantity: 2
Cooling method: water-cooled
Motor names: fan high-pressure pump motor, oil pump motor
PTO via chassis connection window
Control: electronic, one-button operation, can be operated from cab or rear
Voice alarm system for reversing and operations
Rear electric control for body lift and rear door operation to avoid accidents from limited visibility
Manual pump emergency lift system in case of hydraulic failure, allows raising sweeping brushes, suction, and hopper manually
Keep unauthorized personnel away, especially from the rear
Avoid large debris like bricks during operation
Drain waste water carefully, open rear door only after the discharge valve is closed
Ensure no personnel within 5 m when emptying waste tank
Never access waste compartment while it is elevated and unlocked
The municipal sanitation industry is undergoing rapid transformation as cities worldwide adopt zero‑emission vehicles. Among essential sanitation solutions, Pure Electric Sweeper Trucks have risen in prominence due to environmental requirements, urban air quality standards, and operational efficiency. This guide focuses on the Dongfeng Huashen CL5187TXSBEV pure electric sweeper truck, a representative model in the electric road cleaning segment.
SEO Keywords: electric sweeper truck, pure electric street cleaner, zero‑emission sanitation vehicle, urban sweeper truck, electric municipal truck.
A pure electric sweeper truck is a specialized municipal vehicle designed for cleaning streets, parking lots, sidewalks, industrial sites, and public areas — powered exclusively by electricity rather than diesel or hybrid powertrains.
A pure electric sweeper truck:
Uses battery electric power only
Eliminates tailpipe emissions
Integrates sweeping components such as brushes, suction systems, water tanks, and debris hoppers
Core Functional Components
Main sweeping brushes
Side brooms
Suction fan and debris conveyance
Fresh water spray system
Electric drive system
Purpose: To remove dust, dirt, leaves, litter, and particulate matter from paved surfaces.
Urban sanitation departments deploy sweeping trucks to:
Improve roadside aesthetics
Reduce airborne dust
Control particulate rise
Maintain cleanliness in high‑traffic public spaces
As cities tighten emission regulations, traditional diesel street sweepers are being replaced by electric alternatives to meet air quality targets and reduce noise pollution.
Industry Connections: Air quality improvement strategies, sustainable city maintenance, intelligent waste management, clean transportation initiatives.
The Dongfeng Huashen CL5187TXSBEV is an advanced model within the electric sweeper truck category, offering:
Powered by a zero‑emission battery system, this vehicle operates with quiet performance, no fuel consumption, and reduced operating cost.
Equipped with dual side brushes, a high‑speed suction fan, a large debris hopper, and fresh water spraying to control dust.
Designed for ease of use with comfortable seating, a clear control panel, and an all‑electric drive interface.
Electric sweeper trucks such as the CL5187TXSBEV provide key advantages over traditional combustion models:
Lower Operating Noise: Electric motors produce less noise than diesel engines
Smoother Operation: Electric drive reduces vibration
Reduced Fuel Cost: Electricity is generally cheaper than diesel fuel
High Torque at Low Speed: Ideal for urban driving, sweeping, and maneuvering
These performance traits boost productivity while reducing environmental and community impact.
Adopting pure electric sweepers delivers measurable environmental benefits:
No Tailpipe Emissions: Improves city air quality and meets environmental regulatory standards
Lower Particulate Pollution: Reduces fine dust, road pollution buildup, and secondary particulate generation
Noise Pollution Reduction: Beneficial in residential zones and night operations
Modern electric sweepers integrate technologies from several fields:
High‑capacity batteries, electric motors with efficient torque curves, and regenerative braking systems.
Wear‑resistant brushes, suction fans with optimized airflow, and adjustable brush positioning systems.
Controlled fresh water injection, atomized misting to trap airborne particles, and automatic pump integration.
| Category | Specification |
|---|---|
| Model | CL5187TXSBEV |
| Type | Pure Electric Sweeper Truck |
| Powertrain | Electric Motor Only |
| Wheelbase (mm) | 3800–4600 |
| Gross Vehicle Weight (kg) | 10,000–12,000 |
| Feature | Details |
|---|---|
| Power Output | 100–150 kW electric motor |
| Maximum Speed | 50–60 km/h |
| Driving Range (Full Charge) | 150–250 km |
| Battery Type | Lithium‑ion Battery Pack |
| Charging Time | 6–8 hours (standard charger) |
| Component | Capacity |
|---|---|
| Main Brush Width | 1200–1400 mm |
| Side Brush Diameter | 500–600 mm |
| Water Tank Volume | 800–1200 L |
| Debris Hopper Volume | 4–7 m³ |
| Suction Fan | High‑Efficiency Centrifugal |
| Parameter | Value |
|---|---|
| Turning Radius | ≤7.5 m |
| Gradeability | ≥20% |
| Ground Clearance | 180–220 mm |
| Noise Level | ≤75 dB (typical) |
Electric street sweepers like the CL5187TXSBEV are widely used in urban streets, sidewalks, pedestrian zones, industrial sites, airports, train stations, bus terminals, and residential communities. They are ideal where low noise and clean emissions are priorities.
Proper maintenance ensures longevity and safety.
Electric System: Monitor battery health, run regular diagnostics, and keep charging components clean.
Sweeping Components: Inspect brushes, check suction fan wear, and replace water pumps as needed.
Daily Checklist: Charge battery, empty debris hopper, inspect electrical cables, clean side brooms, monitor water tank level.
Operators should understand electric system operation, emergency shutdown procedures, and proper brush and suction settings. Avoid deep water immersion, sharp debris, and extreme slope sweeping. Safety features include backup alarms, rearview cameras, and operator alert systems.
Adoption is driven by emission regulations, technological advancements like improved battery density and telematics, and urban sustainability goals. More cities integrate electric sanitation fleets into smart city plans for clean, quiet, and efficient municipal operations.
Difference from Hybrid Sweepers: Pure electric runs solely on electricity, hybrids combine electricity with combustion.
Battery Range: Typically 150–250 km per full charge.
Cost-Effectiveness: Lower fuel and maintenance costs result in reduced lifecycle expenses.
Cold Weather Performance: Electric sweepers operate in cold climates but battery efficiency may decrease.
The Dongfeng Huashen CL5187TXSBEV Pure Electric Sweeper Truck represents a new generation of zero‑emission sanitation vehicles, combining advanced sweeping systems, electric drive technology, and industry‑standard design. Electric street sweepers balance performance, sustainability, and cost-efficiency, making them essential for modern urban maintenance.
